Argon IOn Laser
high power CW Argon-Ion Lasers
Cw mid-uv Argon-ion Laser
The Argon-ion lasers is a very powerful & versatile; providing multi-line output plus tunable single-line wavelength.
Utilising a precise, high purity BeO plasma tube with crystalline quartz optical windows for superior transverse mode and lifetime. The high-quality TEM00 beam laser is suitable even for highly mode-sensitive applications. |
SPECIFICATIONS
Beam diameter^2 (@ 1/e2 points) 1.1 mm @ 514. 5 nm TEM00 (Argon) 1.2 mm @ 647.1 nm TEM00 (Krypton) Beam divergence^2 (full angle) 0.7 mrad @ 514.5 nm TEM00 (Argon) 0.9 mrad @ 647.1 nm TEM00 (Krypton) |
cw duv argon-ion laser
Argon Laser provides true continuous-wave deep ultraviolet from 229nm to 264nm with outputs up to 200mW, plus tunable visible wavelengths from 457nm to 528nm.
It is also fast and efficient; designed to be easily switched from Deep-UV to visible with tunable output over a full range of wavelengths. Utilising a precise, high purity BeO plasma tube with crystalline quartz optical windows for superior transverse mode & lifetime. |
SPECIFICATIONS
Beam diameter^2 (@ 1/e2 points) ≤ 1.3 mm/≤ 1.5 mm^5 @ 514. 5 nm TEM00 (Argon) ≤ 1.3 mm/≤ 1.5 mm^5 @ 647.1 nm TEM00 (Krypton) Beam divergence^2 (full angle) 0.6 mrad @514.5 nm TEM00 (Argon) 0.9 mrad @ 647.1 nm TEM00 (Krypton) |
low energy argon-ion laser
This series of Argon-Ion is designed to be retrofitted into other types of instrumentation or systems.
It is designed to be ruggedised; its made hard-sealed laser tube and state-of-the-art power supply both combined into a single package. This series is available in a very wide range of wavelengths, with maximum output up to 1000mW. |
SPECIFICATIONS
Wavelength 457.9nm – 514.5nm (differ across models) Maximum Output Power 10mW - 1000 mW (each model with its own o/p) Beam Mode TEMoo |
related instruments
Spectroscopic Systems
|
Raman Spectrometers - for Raman light source
|
|
