dEEP uv lASERS

D​eep UV lasers are ideal for applications such as Raman spectroscopy where the narrow line width is a requirement.  The deep UV LEDs are useful for compact fluorescence based instrumentation where the smaller size and lower cost are key benefits.
DUV laser singapore
HeAg @ 224.3nm
duv laser singapore
NeCu @ 248.6nm
The DUV family of lasers offer 224.3 nm and 248.6 nm for fraction of
the cost of the competition. The laser is the size, weight and power
consumption of a HeNe laser but with output in the deep UV. The selfcontained, integrated, laser controller enables remote computer
control for ease of operation and flexible data collection via LabView
software. ​
SPECIFICATIONS

HeAg lasers
@ 224.3nm

Peak Power (quasi-cw)
>50 mW (HeAg 70)
>10 mW (HeAg 30)
System Dimensions
10x10x70 cm (HeAg 70)
5x13x30 cm (HeAg 30)
System Feight
3.6 kg (HeAg 70)
1.4 kg (HeAg 30)
Pulse Frequency
1 – 20 Hz (HeAg 70)
1 – 5 Hz (HeAg 30)
Longitudinal Mode Spacing
257 MHz (HeAg 70)
642 MHz (HeAg 30)
Pulse Width
20 μS to 120 μS, adjustable ​
NeCu lasers @ 248.6nm

Peak Power (quasi-cw) >250 mW (NeCu 70)
>50 mW (NeCu 30)
System Dimensions 10x10x70 cm (NeCu 70)
5x13x30 cm (NeCu 30)
System Weight
3.6 kg (NeCu 70)
1.4 kg (NeCu 30)
Pulse Frequency
1 – 20 Hz (NeCu 70)
1 – 5 Hz (NeCu 30)
Longitudinal Mode Spacing
257 MHz (NeCu 70)
642 MHz (NeCu 30)
Pulse Width
20 μS to 50 μS, adjustable ​
