Radiation Educational setup
GM COUNTING SYSTEMS
The Intermediate Nuclear Lab System provides the ultimate in nuclear lab systems for studying the characteristics of radiation.
Operated using a computer (PC or Mac) via a serial or USB connection, this allows for data to be collected and displayed on the screen in either analog or digital format. All of the data is stored in a format that can easily be transferred directly to many common spreadsheet programs. The Intermediate Nuclear Lab System also comes with a set of 5 U.S. NRC exempt quantity sources (RSS5 or RSS5EU for international orders): 1- alpha, 2-beta, and 2-gamma emitters. This allows users to study the characteristics of different types of radiation. |
SPECIFICATIONS
Operating Modes Count, Count Rate, High Voltage, Time, Alarm Point, Speaker Volume 6 decade digital display GM detector assembly complete with sample holder (six positions, 1 cm separation) and BNC cable (3 ft) 20 piece absorber set Aluminum, plastic, lead (4.5 to 7367 mg/cm2) Set of 5 radioactive sources 1 alpha, 2 beta, 2 gamma emitters Experiment Lab Manuals Instructor and Student Editions D version with sample data |
SCINTILLATION COUNTING SYSTEM
The Wipe/Test Tube Counting System is built around the Radiation Counter and a 1.75″ x 2″ NaI(Tl) well detector. The Wipe/Test Tube Counting System also comes with a single U.S. NRC exempt quantity test tube source (CS137TS.1): 1- gamma emitter.
This system is ideal for counting wipes and test tube samples. |
SPECIFICATIONS
Operating Modes Count, Count Rate, High Voltage, Time, Alarm Point, Speaker Volume 6 decade digital display Well detector assembly Cs-137 test tube source, 0.1 μCi (3.7 kBq) +/- 10% |
Radiation SPECTROSCOPY SYSTEMS
The Universal Computer Spectrometer System (UCS) is a complete spectroscopy system designed for nuclear science instruction. The System is built around the UCS and a 1.5″ x 1.5″ NaI(Tl) detector; it is designed for conducting a wide selection of spectroscopy experiments.
The UCS-30 contains either a 1024, 2048, or 4096 channel MCA with an internal pre-amplifier, computer controlled amplifier, high voltage, upper and lower level discriminators, ADC, and Multichannel Scaling for half-life and decay studies.Also included is a Mossbauer interface and preamplifier power output (±12 V) for connecting detectors with external preamplifiers such as proportional counters and CdZnTe probes. The system can be operated using a computer (PC or Mac) via a USB connection. The System also comes with a set of 8 U.S. NRC exempt quantity sources (RSS8, RSS8EU, or RSS8UN for international orders): 8-gamma emitters. |
SPECIFICATIONS
Scintillation detector assembly Sample holder (six positions, 1 cm separation) 11 absorber plates Aluminum, plastic, lead (4.5 to 7367 mg/cm2) Set of 8 radioactive sources 8 gamma emitters Experiment Lab Manuals instructor and student editions |
|
*Pictures shown above are for reference only. Actual product may differ slightly.
**Some products may not be available in all countries. Please contact us for further information and clarification. |
