This LaVision High-Speed 2D PIV System is employed to acquire comprehensive insights into the swash flows generated by a train of solitary waves and the concurrent turbulence structure. This system conducts two-dimensional velocity measurements utilising a 100-Hz high-speed particle image velocimetry (HSPIV) technique.

Our engineering team has assisted aixacct in the technical support in the aixDBLI system.

The Industrial Line DBLI systems offers manufacturers of piezoelectric MEMS products the ability to monitor quality in the production process for the first time.

This was a customised solutions that Analytical Technologies has worked with EVERBEING for probing onto your PCB boards, accommodating a range of sizes according to your specifications. Our stations seamlessly integrate with various applications, including DC, RF, mmW, and High Temperature capabilities. Certain models also support double-sided probing (top and bottom) for enhanced versatility.

Our local technical support team has successfully commissioned a semiconductor variant of the world renowned LabRAM Evolution Confocal MicroRaman System.  Fully equipped with multiple lasers from UV to NIR and  unique upgrades, the system is able to handle Raman as well as Photoluminescence measurements.

The LabRAM Confocal MicroRaman system microscopes are ideally suited for both micro and macro measurements, and offer advanced confocal imaging capabilities in 2D and 3D. The true confocal Raman microscope enables the most detailed images and analyses to be obtained with speed and confidence.  It is widely used for standard Raman analysis such as PhotoLuminescence (PL), it can also be further integrated for other hybrid analysis.

The NanoRaman system equipped with LabRAM Evolution being installed locally by Analytical Technologies' in-house team.

LabRAM Evolution, the world renowned Raman solution for research and analysis. The integral flexibility of the LabRAM HR Evolution makes it the ideal platform for combined with the fully integral nano-Raman for research to TERS (tip enhanced Raman scattering).

A close up of the integration of a customised environmental chamber and electrochemical cell within a NanoRaman (as shown above) setup designed a sophisticated and versatile experimental configuration to enhance the capabilities of this analytical instrument.

This integrated system is further augmented by the inclusion of a bipotentiostat, a critical component for conducting Tip Enhanced Raman Spectroscopy (TERS) experiments.
​​

Personalised hands-on guidance and training provided by a HORIBA's application scientist represents a valuable and tailored educational experience designed to empower researchers, technicians, and users with the skills and knowledge required to make the most effective use of HORIBA's instruments.

Another angle of the HORIBA's LabRAM HR Evolution Setup before the integration of NanoRaman, with HORIBA's in-house software installed in the computer (right).

LaVision's Two-Color Pyrometry setup provides a robust system for temperature measurements. It demonstrates the precise measurement of flame temperature, showcasing the system's accuracy and capability. Additionally, the calibration process is conducted using a filament lamp, ensuring the system's reliability and accuracy through meticulous calibration procedures

​Image:
​Clean and sleek layout of the QPatch.

​Our technical support team testing and commissioning the Horiba Xplora Plus MicroRaman system.  The system installed has multi excitation laser lines and Class 1 cover.
