Scanning Electron Microscope (SEM)
SELPA
SELPA(Scanning ELectron Microscope for Particle Analysis) is an automated large area particle analyzer, which is developed based on SEM(Scanning Electron Microscope)
In industrial application, it can be used to analyze and classify the particles by their various size and element, the strength of SELPA is that the large area mapping is possible. Also, SELPA can analyze particles under 2.5um, it's a SEM/EDS automated system which can get the results of elements distribution of selected area. |
FEATURES
Electron Gun
Pre-centered Cartridge Source Tungsten (W) Magnification x60 to x5,000 Acceleration Voltage 1 to 30kV (1kV increment) Detector BSED(DP) Stage X: 100mm (Motorized) Y: 100mm (Motorized) Z: 12 to 40mm (Motorized) |
EM-30N : Benchtop SEM
The EM-30N is the ultimate benchtop SEM, with N meaning the unlimited potential of discovery of physical & biological worlds.
The EM-30 series is best for applications with spatial restriction or applications for smaller samples. |
FEATURES
Dimension 400 x 600 x 550 mm Weight 85kg Resolution <5nm (EM-30N EM-30Plus EM-30AXPlus) <15nm (EM-30 EM-30AX) Options STEM |
EM-30 PLUS : BENCHTOP SEM
EM-30 : BENCHTOP SEM
The EM-30 series is best for applications with spatial restriction or applications for smaller samples.
|
CX-200PLUS: Full SEM System
CX-200PLUS is a full & holistic SEM system including a software system with a greater magnification level as compared to the benchtop model. It is ideal for larger specimens (up to 160mm diameter) or when space is not a restriction.
The CX-200PLUS also has a more adjustable X,Y & Z axis to allow the application to be much faster & more accurate. It is ideal for applications such as signal mixing with up to 3nm resolution. CX-200PLUS provides multiple useful techniques such as SE, BSE, and cool stage, making it ideal to investigate morphological structures of biological specimens. |
FEATURES
Compact and Strong Performance Resolution <3nm Standard SE, BSE Detector Standard Chamber Scope Standard Panorama Signal Mixing Fully Compatible EDS 10 Ports for Third party |
related instrument
Optional Products
|
|
*Pictures shown above are for reference only. Actual product may differ slightly.
**Some products may not be available in all countries. Please contact us for further information and clarification. |
